HEWEI EOD Robot
Introduction
EOD Robot is a high-tech equipment designed specifically for Anti-terrorism, EOD, public safety and other fields. It can replace EOD personnel to perform tasks such as reconnaissance, transfer, dismantling and destruction of explosive devices or hazardous items. Through remote control, it can replace people entering high-risk environments, significantly reducing the risk of casualties, and is widely used in military, special police, firefighting, customs and other scenarios.
Product Features
1. High Flexibility and Mobility
①All-terrain Adaptability: Equipped with a track + swing arm composite chassis, it can easily cope with complex environments such as stairs, gravel, swamps, and snow. The maximum climbing angle is ≤45°.
②360° Operation: It can turn in place and operate flexibly in narrow spaces.
③Flexibility: For different operation requirements, different models of robotic claws can be replaced to perform tasks.
2. Precise Operation Ability
① Multi degree of freedom robotic arm: 6-axis high-precision robotic arm, rated load of 25kg, maximum load of 50kg, end repeat positioning accuracy ± 1mm, supports cutting, grasping, drilling, egg clamping and other operations.
② Modular design: Adopting the modular design concept, functional modules such as water exploder disrupter, portable X-ray machine, sound wave disperser can be quickly replaced through standard interfaces, flexibly adapting to diverse task requirements.
③ Modular battery, quick change, good task assurance.
3. Safety and Reliability
① Autonomous obstacle avoidance: Equipped with ultrasonic sensors, it accurately detects obstacles within 1.5 meters, automatically warns and avoids them, and has reliable obstacle avoidance capabilities.
② Emergency protection: Equipped with a one button emergency switch, it can instantly cut off the power supply in case of operational errors or danger, providing safety assurance for equipment operation.
③ Chassis with brake, it will brake when the power is cut off..
Technical Specification
|
Basic Parameter |
|||
|
Size |
EOD Robot |
1000×760×840mm（Excluding camera） | |
| 1000×760×1100mm（Including camera） | |||
|
control box |
545×434×193mm | ||
|
Weight |
EOD Robot |
Approximately 230kg | |
|
|
control box |
17.5kg | |
|
Display screen |
10.1-inch touch screen+18.5-inch monitor (control box) | ||
|
Chassis structure |
Aluminum | ||
|
Distance from ground |
8cm | ||
|
Protection grade |
IP65(Robot) | ||
|
Maximum height of the entire |
270cm（including installed robotic arm） | ||
|
Power and Endurance |
|||
|
Battery configuration |
robot | 50Ah | |
|
|
control box | 18Ah | |
|
Charger specification |
Robot charger | 48V/10A | |
| Control box charger | 29.4V/5A | ||
|
Duration |
Standby duration (robot) | ≤30h | |
|
Working hours |
robot | 2.5 - 3h， | |
|
|
control box | About 12h | |
|
Charging duration |
robot | 5 - 6h， | |
| control box | 3.5~4h | ||
|
Power supply interface |
Support 110VAC -220VAC, 50/60HZ AC input | ||
|
Power |
robot | Standby power ≤ 70W; Low speed power ≤ 350W; Medium speed power ≤ 600W; High speed power ≤ 850W; Load capacity ≤ 2300W; Dragging power ≤ 2800W | |
| control box | Working power ≤ 25W | ||
|
Application Performance |
|||
|
Drive system：dual drive, rubber track size diameter 310mm * width 100mm; Double swing arm, effective length 480mm; |
|||
| Three speed transmission: Low gear: 1.57km/h（0.43m/s） (hill climbing), Medium gear: 3.13km/h(0.86m/s), High gear: 6.26km/h（1.48m/s） | |||
|
Dragging weight and Load capacity |
Dragging weight |
≥ 150kg (When the maximum drag weight is reached,Correspondingly reduced load capacity) |
|
|
|
Load capacity |
≥ 150kg (when the maximum load capacity is reached, the drag capacity decreases accordingly) |
|
|
Adaptive terrain |
Support all-round movement, adapt to complex terrains such as stairs, gravel, mud, snow, etc., climb slopes ≤ 45 °, and have obstacle crossing ability of 40cm high and 70cm wide pit | ||
|
|
|||
|
Function Expansion |
|||
|
Quick disassembly components |
Support multiple clamping sizes of grippers, scissor components, cutting and puncture components, and tactile grippers | ||
|
Equipped |
capable of carrying water exploder disrupter, portable X-ray machine, sound wave disperse | ||
|
Other functions |
Shouting function | Remote Shouting function is achieved by installing a stereo 3.5mm audio interface and using sound wave dispersion connection | |
| Monitoring function | It can monitor the sound of the robot's surrounding environment and output sound from the control box speaker | ||
|
Communication and Control |
|||
|
Image transmission frequency band |
Image transmission: 420-450MHz, data transmission: 902-928MHz | ||
|
Effective image transmission distance |
Wireless image transmission ≤ 890m, wired 200m fiber optic cable | ||
|
Control unit |
Joystick controls walking speed, robotic arm posture, recording, lighting, sound and other functions | ||
|
Version Upgrade |
Supports front-end/back-end upgrades | ||
|
Operation Temperature |
-20℃~60℃ | ||
