Portable X-Ray System for EOD and security operations

Short Description:

Portable X-Ray System for EOD and security operations is a light weight ,portable,battery powered x-ray scanning system designed in co-operation with the first responder and EOD teams to meet the need of the field operative. It is light weight and comes with user friendly software that helps operators in understanding the functions and operations in a less time.


Product Detail

Why Choose Us

Product Tags

Product Video

a 66
a 64

Model: HWXRY-03

Description:



Portable X-Ray System for EOD and security operations is a light weight ,portable,battery powered x-ray scanning system designed in co-operation with the first responder and EOD teams to meet the need of the field operative. It is light weight and comes with user friendly software that helps operators in understanding the functions and operations in a less time.

Features:

Can be assembled rapidly on-site.

Imaging plate using amorphous silicon technology,  image is very clear.

Can operate with remote control in the rear.

Powerful image enhancement and Analysis tools.

Intuitive interface, Image splicing infinite,

Simplicity of operation.

User-friendly software.

Specification:

A

Technical Specification of the imaging plate

1

Detector Type

Amorphous Silicon with TFT

2

Detector Area

433mm x 354mm (Standard)

3

Detector Thickness

15mm

4

Pixel pitch

154 μm

5

Pixel array

2816X2304 pixels

6

Pixel Depth

16 bits

7

Limiting Resolution

3.3 lp/mm

8

Image Acquisition Time

4-5s

9

Weight

6.4kg with battery

10

Power supply

220V AC/50Hz

11

Communication

Wired: 50 meters fiber on a roller, TCP/IP Ethernet

Wireless: 5G Wi-Fi , no less than 70m

12

Operating Temperature

-10℃+55

Technical Specification-x-ray Generator

1

Operating Mode

Pulse, it launches 4000 pulses each time when charged fully

3

Working hours More than 5 hours

4

Voltage

150kV

5

Penetration

50mm Aluminium Plate

6

Weight

5.1 Kg with battery

Technical Specification – Imaging Station (PC)

1

Type

Laptop computer

2

Processor

Intel Core i5 processor

3

Display

13 or 14” Full High Definition LED Display

4

Memory

8GB

5

Hard Drive

No less than 500GB

6

Operating system

English MS Windows 10

7

Software

Automatic Optimization, Invert, Revert, Pseudo color image, Rotate, Flip HorizontalFlip Vertical, Zoom, Deep Focus, Polygon

On screen measurement, Merge, Save, 3D image

Applied Scene

EOD/IED:

Widespread use of explosives presents immense growing challenges and threats to civilians, law enforcement forces, military and police bomb squads and EOD teams worldwide. The key objective of Bomb Disposal Operators is to accomplish their task as safely as possible. For that reason, EOD equipment, and specifically portable x-ray scanner systems play a crucial role in meeting this objective -providing real time, high quality images of suspect objects, while ensuring the safety of all parties involved.

The Ultra Portable Inspection X-ray Imaging System is perfect for contraband – drugs or weapons, and IED detection by examination of suspected items across borders and perimeters. It allows the operator to carry the complete system in his car or in a backpack when needed. The inspection of suspected items is quick and simple and provides the highest image quality for on the spot decisions.
